Chrome Moly Pipe

Chrome Moly Pipe refers to the pipe that contain a certain percentage of Chrome and Molybdenum elements, chrome provides corrosion resistance while Moly increases the overal strength, resistance, electricity, hardenability and overall quality. These elemements make the material could suitable for high temperature services and corrosion environment.

Key Features of Chrome Moly Pipe:

1. Material Composition:
   • Typically made from alloy steel with a composition that includes approximately 0.5% to 0.8% chromium and 0.1% to 0.5% molybdenum.
2. Strength and Durability:
   • Chrome moly pipes are known for their high tensile strength and ability to withstand extreme conditions, making them ideal for high-pressure applications.
3. High-Temperature Resistance:
   • These pipes maintain their strength and structural integrity at elevated temperatures, making them suitable for use in power plants, refineries, and other industrial settings.
4. Corrosion Resistance:
   • The addition of chromium provides enhanced resistance to oxidation and corrosion, extending the lifespan of the pipes in harsh environments.
5. Weldability:
   • Chrome moly pipes can be welded using standard welding techniques, allowing for flexible installation and repair options.

Applications:

• Oil and Gas: Used in pipelines and equipment for transporting oil and gas.
• Power Generation: Commonly found in boiler systems and heat exchangers.
• Chemical Processing: Employed in the transport of chemicals and other industrial fluids.

Mainly standard of Chrome Moly Pipe:

ASTM A335 for Seamless, Common use grades in P11, P22, P5, P9, P91
ASTM A691 for Welded, Corresponding to 1-1/4CR, 2-1/4CR, 5CR, 9CR, 91

ASTM A335 Standard Specification

ASTM A335 specificaton covers nominal wall and minimum wall thickness pipe that with alloy material and manufactured in seamless type. The pipe under this specification shall be suitable for bending, flanging, and all the other similar processing and formations. Although it shall be good for fusion welding.

ASTM A335 Grades P11, P22, P91, P92 are prevalent grades for the power industry, and P5 or P9 pipe used for refinery processing.

Chemical Composition

Mechanical Properties

ASTM A691 Standard Specification

ASTM A691 specification covers carbon and alloy steel pipe, electric-fusion-welded with filler metal added, fabricated from pressure-vessel-quality plate of several analyses and strength levels and suitable for high-pressure service at high temperatures. Heat treatment may or may not be required to attain the desired mechanical properties or to comply with applicable code requirements. Supplementary requirements are provided when additional testing or examination is needed.

Mechanical Requirements

Tensile Test – Transverse tensile properties
Transverse Guided Weld Bend Tests
Hydrostatic pressure test classes X2 and X3 pipe shall be tested in accordance with Specification A530/A530M.
Charpy V-Notch Test for pipe with nominal wall thickness of 1/2in 13mm and greater.
Hardness tests
Metallography
Magnetic Particle Examination of base metal and weld metal
Liquid Penetrant Examination of base metal and weld metal
Ultrasonic Test

ASTM A691 Permissible Variations

Outside diameter +/- 0.5%.
Out of roundness – The difference between major and minor outside diameters 1%.
Alignment – Using a 10-ft 3m straightedge placed so that both ends are in contact with the pipe, 1/8in. 3mm.
Thickness – Minimum wall thickness at any point in the pipe shall not be more than 0.01 in 0.3mm under the specified nominal thickness.
Lengths with unmachined ends shall be within -0, +1/2 inch, 0 +13mm of that specified. Lengths with machined ends shall be as agreed between manufacturer and purchaser.

Dimension range:

ASTM A691 covers pipe OD in 16inch and above, wall thickness up to 3inch, 75mm.

Equivalent Material for Fittings, Flanges, Plates

Pipe fittings standard: ASTM A234 WP22
Flange Standard: ASTM A182 F22
Steel Plate Standard: ASTM A387 Grade 22/ ASME SA387 Grade 22
Welded pipe standard: ASTM A691 2-1/4 CR

P22 pipe material has high toughness and high wear and tear resistance, it could be used to manufacture pipe fittings like elbow, tee, reducers in ASTM A234 WP22 chrome moly pipe fittings.

Our Supply Range:

Standard and Grades for Seamless: ASTM A335 / ASME SA335 Grade P11, P22, P5, P9, P11
Standard and Grades for Seamless: ASTM A691 for Welded, Corresponding to 1-1/4CR, 2-1/4CR, 5CR, 9CR, 91
Material types: Chrome Moly Pipe
Manufacturing types: Seamless pipe by hot rolled or cold drawn
Sizes: 1/2” to 24”
Wall thickness: SCH 40, SCH STD, SCH 80, SCH XS, SCH 160
Length: 6 meters, 12 meters or customized.
Surface treatment: Polished, Varnished, 3PE, FBE
Ends: PE (Plain End), BE (Beveled Ends)
